Weight & Capacity

• GVWR: 7,000 lbs

• GAWR: 3,500 lbs per axle

• Curb Weight: 1,860 lbs

• Payload Capacity: 5,140 lbs

Dimensions

• Deck Width: 62 in

• Deck Length: 120 in (10 ft)

• Overall Length: 165 in

• Overall Width: 5 ft

• Deck Height: 26 in

• Coupler Height: 15.5 in

Interior Box Dimensions

• Interior Length: 120 in

• Interior Width: 62 in

• Interior Height: 16 in

Frame & Construction

• Frame: 5" x 2" steel tube

• Tongue: 4" x 2" steel tube

• Crossmembers: 3" steel channel

• Decking: 11-gauge smooth steel

• Sides: Integrated side body stiffening system

• Exterior Finish: Industrial-grade polymer coating

Axle, Suspension & Running Gear

• Axle: 3,500 lb spring brake axle

• Hubs: Easy Lube

• Tires: ST205/75R15C, 6-ply

• Wheels: 15" steel, 5-lug

• Fenders: Double brake tread plate

Hydraulic System

• Hydraulic Pump: 12-volt

• Operation: Power up / power down

• Cylinder: Single ram

Electrical & Lighting

• Electrical System: 12-volt DC, 24 battery

• Connector Plug: Round 7-pin blade

• Exterior Lighting: Full LED, DOT compliant

Coupler & Safety

• Coupler: 2-5/16" A-frame

• Safety Chains: DOT compliant

• Breakaway System: Battery, switch, and lanyard

• Tongue Jack: 2,000 lb coupler-mounted

Doors, Storage & Accessories

• Rear Door: Barn-style double doors with cambar

• Tie-Downs: (5) 1/2" D-rings with stake pockets
